Earthing and short-circuiting device
MT-5805
New product
Earthing and short circuiting system for direct mounting on live conductor.
More info
Composition
- 3 live conductor clamps MT-815-C.
- 1 earth clamp MT-840/1.
- 1 assembly of 3 round copper cable connecting braids with a transparent silicon sheath. Section 95 mm2, length 1,5 m. 1 round copper earth cable with transparent silicon sheath, section 35 mm2 and length 2,5 m.
- The connection point between phase conductors and earth conductor is coated with insulation.
- 1 plastic case.
Characteristics
- Short-circuit rating: 20 kA / 1 s.
- Clamps capacity Ø 5 to 35 mm- plate thickness 5 to 40mm
- Case dimensions: 650 x 480 x 210 mm.
- Total weight : 5 kg
Optional accessories :
- Stick CE-4-21-C
- Stick carrying bag : CM-1-10
